12V/24V Auto 10A~80A Work MPPT Solar Charge Controller
-
Min Order
1
-
Product Unit
Pieces
-
Origin
China Mainland
-
Payment
- Contact Now Start Order
- Favorites Share
- Description
Product Detail
12V/24V auto 10A~80A work mppt solar charge controller
Description:
-10A/20A/30A/40A/60A/70A/80A MPPT Solar charge controller
-12V/24V auto work
-MPPT efficiency>99%,Peak conversion efficiency >98%
-Protection:PV array short circuit,
PV reverse polarity,Battery reverse polarity, Over charging, Output short circuit
The MPPT Solar Controller Maximum Power Point Tracking Charge Controller offer an efficient, safe, multi-stage recharging process that prolongs battery life and assures peak performance from a solar array.
Compared to conventional PWM controller, MPPT technology increases the charge efficiency up to 30% and potentially decrease the power of solar array needed.
This type controller uses intelligent battery charge and discharge management, with temperature compensation attached, better manage the battery and extend battery use life, Also it integrates RS485 communication interface, providing communication protocols, enabling customers to remote manage a unified and integrated, with comprehensive protection and brand material to make sure it a long time use.
Features:
Advanced MPPT algorithm with the max. tracking efficiency of 99%
Multi-phase synchronous rectification technology realizing peak conversion efficiency 98%
Dualcore(ARM CPU+DSP) control architecture improves the system response speed and optimizes the performance of the system
Multi-phase control technology, optimizes charging current smoothness, reduces ripple and improves the system efficiency
LCD intuitively displays data and state?
Four battery type options: Sealed, Gel, Flooded and User-defined
Energy statistics recording, it is convenient for users to view charging and discharging energy of each day, month, year and total value
Diversified load control mode
Programmable battery management parameters
Built-in running data and event logging max. 15 months
Extensive communication capabilities (RS232,RS485 with Modbus protocol, CAN Bus extendable)
PC software available for real time monitoring and parameter setting
Field up-gradable firmware
Model | SCM12-20S/SCM24-20S | SCM12-30S/SCM24-30S | SCM12-40S/SCM24-40S | SCM12-50S/SCM24-50S | ||
PV INPUT | ||||||
PV System Power(W) | 250/500W | 380/750W | 500/1000W | 750/1500W | ||
PV System Max Output Current(A) | 20A | 35A | 45A | 55A | ||
MPPT Working Voltage Range(VDC) | 18V-30V for 12V standard battery group; 30V-80V for 24V standard battery group | |||||
PV System Max Voltage(VDC) | 90V(the PV panel output max voltage) | |||||
Recommend PV System Output Voltage(VDC) | 20V for 12V battery group /40V for 24V battery group | |||||
PV Input Reverse Protection | Yes | |||||
Output Charging Data | ||||||
Output Voltage Type | 12V/24VAutomatic Recognize | |||||
Output Voltage Range(VDC) | for12V battery(10.8V-14.1V) / for 24V battery(21.6V-28.2V) | |||||
Output Over Voltage(VDC) | For 12V battery(15VDC) / for 24V battery(30VDC) | |||||
Charging Current (A) | 20A | 30A | 40A | 50A | ||
Over Charging Current Protection(A) | 21-24A | 31-34A | 41-44A | 51-54A | ||
Output Revers Protection | Yes | |||||
Output Short Circuit | Yes | |||||
Other Parameter | ||||||
PV Convert Efficient | =96.0% | |||||
MPPT Tracking Efficient | =99.5% | |||||
Standby Power (W) | =10W | |||||
Noise dB(A) | =55 | |||||
Radiating | Force cooling by fan,the fan on/off controlled by the temperature | |||||
Ingress Protection | IP20 | |||||
Communication | RS485(optional) | |||||
Display | LCD+LED | |||||
Data Record | 200 records | |||||
Running Temperature (?) | -20 ~ 55? | |||||
Storage Temperature(?) | -40 ~70? | |||||
Relative Humidity | 0~95%,no condensation | |||||
Working Altitude(m) | <3000m (over 3000m,every increase 500, the output will decrease 10%) | |||||
Size(L*W*H )(mm) | 200*170*74mm | 230*180*70mm | ||||
Weight(kg) | 1.6kg | 2kg | ||||
Sturdy New Energy is known as one of the leading 12v/24v auto 10a~80a work mppt solar charge controller manufacturers and suppliers. We have a professional factory with many energy power products in stock at your service which can offer you the wholesale service at reasonable price.
-
