Solar Power Generation System

Min Order

1
Product Unit

Pieces
Origin

China Mainland
Payment
Contact Now Start Order

Description

Product Detail

Product Description

SX-TYNFDXT-01

SX-TYNFDXT-02

SX-TYNFDXT-03

SX-TYNFDXT-04

SX-TYNFDXT-05

MONO-CRYSTALLINE SOLAR PANEL

10-315 Technical Parameters
Power(W)	10W	65W	110W	150W	200W	245W	295W	315W
The maximum power(W)	10	65	110	150	200	245	295	315
The maximum voltage(V)	17.5	18	18	18	37.3	30.4	36.5	36.8
The maximum Current(A)	0.57	3.61	6.11	8.33	5.42	8.06	8.1	8.56
The open circuit voltage(V)	21.6	22.6	21.6	22.6	45.5	37.2	45.4	45.8
Short circuit current(A)	0.61	3.79	6.7	8.73	5.85	8.62	8.73	9.04
The maximum system voltage	UL1703:600VCD&IEC61215/IEC61730:1000VDC
Working temperature	-40~+85
Mechanical strength	5400Pa
Weight(KGS)	1.05	5.06	8.4	10.05	15	18.5	22	22

POLY-CRYSTALLINE SOLAR PANEL

10-310Technical Parameters
Power(W)	10W	60W	100W	130W	150W	230W	245W	300W
The maximum power(W)	10	60	100	130	150	230	245	310
The maximum voltage(V)	17.5	18	18	18	18	30.1	30.4	36.3
The maximum Current(A)	0.57	3.33	5.55	7.22	8.33	7.69	8.07	8.55
The open circuit voltage(V)	21.6	22.6	22.6	21.6	22.6	37.2	37.5	45.2
Short circuit current(A)	0.61	5.82	5.82	7.92	8.73	8.58	8.89	9.07
The maximum system voltage	UL1703:600VCD&IEC61215/IEC61730:1000VDC
Working temperature	-40~+85
Mechanical strength	5400Pa
Weight(KGS)	2.1	5.06	6.6	10.5	10.5	18.5	18.5	22

Optimal working scope:

Our mobile power station mainly use for Resistive load as household linghting, TV, fan, radio and computer. Not suitable for Capacitive load

As electric motor, refrigerator, air conditioning, Microwave and ovens.

In urgent case, our solar multifunction generator can connect with automobile battery to start automobile.

Lighting function

Open the total power switch, if LED in yellow which indicate the battery capacity in good status, open the lighingt switch, the lighting lamp stat working; If LED turn red, the battery is in low voltage status, please charge immediately.

Output by AC function

Open the total power switch and AC switch in tandem, green LED lights, voltmeter indicate the current-voltage AC voltage. When not use AC, please turn AC switch off to save battery power.

Charge function

The power system has two ways of charge battery: Solar panels and AC adapter

Charge Notices

AC adapter charge: While AC power is available, please charge battery with AC Adapter.

Non-matching adapter shall not be used, Otherwise, the battery will damaged.

Solar charge

Place solar panel outdoors and remove all covering on surface of solar panels, make sure solar panels face sun in south direction to absorb sunlight fully, . Then plug the power line of the solar panels into " Solar charging& charging adapter " socket. The adopted solar panels with peak power range: 10W-80W. ( Monocrystalline or Polysilicon solar panels), and fully charge time vary with different solar panels.

Our Services

Provide professional person to communicate with you before the order.

Provide permanent magnet generator with advanced technology, exquisite workmanship, top design.

Provide strict quality check for each part, each process before export.

Provide optimum system solution based on each client’s specific requirement and local location’s weather condition.

Provide complete post-sale service, including installation, technical guide and training.

Packaging & Shipping
