P4 Indoor Rental LED Display

  • Description
Product Detail

P4 indoor rental LED display

P4  indoor rental LED display with 512X512mm high precision & lilght-weight die-casting cabinet,M/W power supply, high fresh rate driving IC

Blue color, black color, orange color, red color & other customized color available

40000 modules stock and more than 800 cabinets newly produced cabinet stock with factory direct price.













P4 indoor rental LED screen

cases



Module configuration(Pixels quantities of the module)L64
H32
Module dimensions(mm)L256
H128
Cabinet configuration(Module quantities of the cabinet)L2
H4
Cabinet dimensions(mm)L512
H512
W65
? Technical Specification of P4mm:
Pixel configurationSMD 3 IN 1(Black LEDs)
LEDs configurationRed: wave L: 625~630nm;700-800mcd
Green: wave L: 525~530nm;1500-1800mcd
Blue: wave L: 470~475nm;400-500mcd
Pixel pitch(mm)4
Pixel density(dots/?)62500
Calibrated brightness(cd/?,nit) 1400 nits(adjustable)
Calibrated brightness proportion ratioR: G: B = 30%:60%:10%(adjustable)
Color temperature3,500° — 9,500° K(adjustable)
Contrast ratio4,000:1(adjustable)
Brightness adjustment(dimming)100 grade auto/manual-adjustment
View angle(degree)(50% brightness) Horizontal/Vertical: 140° (70° off center)
Readability viewing angleHorizontal/Vertical: 140° (70° off center)
Color capability4.4 trillion
Refresh rate(Hz)>4000 Hz(adjustable)
Frame frequency(Hz)>60 Hz
Interface portDVI interface(DVI connector)
Input signalVGA, Video, AVI, MOV, MPG, DAT, VOB etc.
Protection gradeIP65 front side/IP20 backside
LED Drive Constant-current drive
Lifetime(hours)(50% brightness) 100,000 hours
Signal transmission directionHorizontal
Operating temperature(Celsius degree)-15~+55'
Storage temperature(Celsius degree)-30~+65'
Operation humidity(RH)0-95%
Operation humidity(RH)0-99%
ServicingFront and back serving optional
Control modeSynchronous & asynchronous available
Communication optionsWire Ethernet, Fiber Ethernet,RF wireless,GPRS
Power120/240 V AC single phase(50-60Hz)
Maximum power consumption(W/?)400
Average power consumption(W/?)160
Screen operation mode(scan/static) 1 / 16
