Grinding Wheel For Corrugated Industry

Min Order

1
Product Unit

Pieces
Origin

China Mainland
Payment
Contact Now Start Order

Description

Product Detail

Grinding Wheel For Corrugated Industry

Among those famous China grinding wheel for corrugated industry manufacturers, Yinglong Superhard Materials Manufactory is a professional such supplier, welcome to buy tcy grinding stone, grinding stone for carton box, marquip grinding stone, slitter grinder production with our factory.

Grinding wheel for Corrugated Industry
General Information;
In Carton Box industry, Grinding Wheels are often equipped as the famous corrugated producing lines, like BHS, AGNATI, MARQUIP, MINGWEI, TCY, HEISH HSU, JUSTU, J.S, KAITUO etc. Two kinds of Grinding Wheels could be used in this field, Diamond Grinding Wheel and CBN Grinding Wheel.
Grinding Wheels are used for sharpening Slitting Blades for slitting the Carton Board. Every certain time, the Slitting Blades needs to be sharpened and keep its sharpness, aiming to keep the Cutting Result of Carton Board, Keep Tidy and Clean and Straight.
According to the different features of Diamond Grinding Wheels and CBN Grinding Wheels. The chosen of Grinding Wheel is totally different.
Diamond Grinding Wheel could be matched with Tungsten Carbide Blade;
CBN Grinding Wheel could be matched with High Speed Steel Blade.
Regular Size of Grinding Wheels for different corrugate producing line.

Item	Machine	Standard Size(MM)	Machine	Standard Size(MM)
Diamond Grinding Wheels CBN Grinding Wheels	BHS	D50T10H16W2.5X3	ISOWA	D50T15H17W6X3
		D50T10H16W4X2	K&H	D60T12.5H17W6X3
		D50T10H19W4X2	FOSBER	D70T13.5H20W6X4
	AGNATI	D70T10H10W3.5X3	FOSBER	D70T17.5H19W6X4
	AGNATI	D50T22H28W3.5X3	Champion	D50T14H15W7X3
	MARQUIP	D50T13.3H15.875W6X1.5	JUSTU	D50T10H16W3.5X3
	TCY	D50T20H15W7X5	KAITUO	D50T10.55H19W6X3
	HEISH HSU	D50T13H15*W7X3	MINGWEI	D50T14.5H19W6X3
	J.S	D50T15H15W7X3	J.S	D50T10H16W7X3
Grinding Wheels could be produced as the customer’ drawing;
