CRC Steel Sheet DC01

Min Order

1
Product Unit

Pieces
Origin

China Mainland
Payment
Contact Now Start Order

Description

Product Detail

CRC steel sheet DC01 is under Europe standard - EN10130, the most popular grade under this standard. Except DC01, we can supply DC02, DC03, DC04, DC05, DC06 under the same standard EN10130. At the same time, we can supply CRC according to other standards - JIS G3141 / ASTM 1008 / EN10130 / DIN1623.1. We have more than 10 years experience in CRC sales. We have long term and good cooperation with many big national steel mills in China. And in our domestic company in Shanghai, the monthly stock is about 20,000 tons.

Specification

Commodity	Cold Rolled Steel Coil
Standard	JIS G3141 / ASTM 1008 / EN10130 / DIN1623.1
Grade	SPCC,SPCD,SPCE,SPCF,SPCG/CS TYPEA/B/C, DS TYPE A/B, DDS, EDDS/DC01,DC03,DC04,DC05, DC06/ST12, ST13,ST14/15,BSC2,ST16
Thicknees	0.3-3.0MM				Width		600-1500MM
Surface Treatment	Oiled		Unoiled		Coil Weight(Min or Max)		5-25 tons
Coil Inner Diameter	508mm		610mm		Coil Outer Diameter(Max)		2000mm
Application And Features
With good weldability, formability and machinability, the product are mainly used in building,application,automobile and general structure
Commercial Steel			Drawing Steel			Deep Drawing Steel
Machanical properties of cold rolled steel
Symbol of quality	Yield Strength Mpa=	Tensile Strength Mpa=	Elongation(L0=50mm,b=25mm) %=						Tensile Piece
			Thickness ,mm
	=0.25		<0.25	0.25~<0.4	0.4~<0.6	0.6~<1	1.0~<1.6	=1.6
SPCC	--	--	30	32	34	36	37	38	No.5,in rolling Direction
SPCD	--	270	32	34	36	38	39	40
SPCE,SPCEN	210	270	34	36	38	40	41	42
Finish Treatment
Surface Finish	Symbol	Remark
Dull Finish	D	A matt finish produced with a roll roughened its surface mechanically or chemically
Bright Finish	B	A smooth finish produced with a roll finished it surface smoothy.


Quality:

Our company has ISO certificate. We always insist on supplying reliable quality products to buyers. We inspect quality during producing and submit quality report to buyer together with all other shipping documents. Or the buyer arranges SGS inspection before shipment.


Inquiry/order information:

No.	Item	Example
1	grade	DC01
2	Surface treatment	oiled
3	size	0.60x1000mm
4	quantity	500 tons
5	Coil inner diameter	508mm
6	Coil weight	5-8 tons
7	Package	Standard export package
8	Application	stamping
9	Shipment	In 20ft containers by sea
10	Delivery	About 20 days
11	Payment terms	TT
