Big Plastic Block And Lump Shredder Machine

  • Description
Product Detail

Big Plastic Block and Lump Shredder Machine


Product Description of Big Plastic Block and Lump Shredder Machine:

Specification:

Hydraulic pusher, an independent power system, the structure solid, smooth running, a big chunk of the large bundle of plastic can tear up, feed easily, large capacity.


Spindle from the gear box drive, smooth running, low noise, large torque

PLC program control system, automatically rotating, stop and realize fully automatic operation of equipment, safe and reliable running of the machine


Blade material: Japanese Brand: SKD-11, knife with "V" shaped installation, so that the blade material cutting across the work evenly, reducing energy consumption, reduce noise; each of the knife has four cutting edges, wear and tear can be rotated 90 ° after the continued use; each to have two cutting edges set, wear can be rotated 180 ° after the continued use; rotor blade  removable, easy to clean, maintain, maintenance.


Electrical control panel: Programmable controller, (PLC: SIEMENS) PLC automatic control system,

counter-rotating and stop automatically are realizable; SIEMENS AC contactor; The working state of every part of the machinery will be show on the panel. There is emergency stop switch on the panel.


Applications of Shredder Machine:
1) Plastic lumps and plastic block, like PP, PE, PET, PC, ABS, Nylon.
2) Plastic pipes, wood
3) PP/PE film, woven bags
4) Living garbage
5) Medical, Electric waste
6) Copper cable, Aluminum cable
7) Wood, Pallet, tree root, solid wood and waste etc.


Main Features of The Shredder Machine:
-Blades are D2 steel.
-The main electrical components are a combination of Siemens and Schneider.
-Microcomputer technology incorporating rotator speed cariations with start, stop and reverse features.
-Automatic reverse sensors to protect the machine against over loading and jamming.
-Specifically designed rotor to be extremely wear resistant.
-Rotor blade can be rotated 4 times before they need changing, lowering running costs and reducing down time.
-Extremely versatile machine able to process a number of different materials.
-Machinery protection, accord with the European CE standard.


MainTechnical Parameter of the shredder:

Model

S1-600

S1-800

S1-1000

S1-1200

Push Power(k\w)

1.5

2.2

2.2

5.5

Mainmotor power(k\w)

18.5

37

37

55

Rotary blade

28

38

48

58

Stationary blade

2

2

4

4

Shaft diameter(mm)

220

400

400

400

Rotate speed(r/min)

90

85

80

75

Capacity(kg/h)

400-600

500-750

600-900

700-1000

Outline dimensionL*W*H(mm)

1800*1215*1850

2700*1700*2350

2700*2000*2350

2700*2300*2350

Payment:
1. 30% TT is down payment as deposit, and 70% is paid before shipment.
2. 30% TT is down payment as deposit, and 70% by irrevocable L/C at sight.
3. 100% irrevocable L/C at sight.


Photos of Big Plastic Block and Lump Shredder Machine:

Big Plastic Block and Lump Shredder Machine

Big Plastic Block and Lump Shredder Machine
