Automatic Bone Paste Ziplock Bag Machine

  • Description
Product Detail

  1. This machine uses fully automatic servo motor with computer digital function to control length, it is easy for operation. The produced one is very tight and fast at the seals, it apparently shows a good quality.



  2. Flow process of production is from rolled material through automatic edge alignment, edge trimming, strip piercing, laminating, ultrasonic compressive embossing, photo cell sensing, hole punching, thermo cutting off and ends with automatic counting, all of the operations are fully automatic.



  3. This machine equips automatic stop equipment, it will work to stop the machine when it is running out of material supply or when photo cell is out of order or when temperature is losing down and below the minimum required.





Main Technical Variables:



Machine modelTPM-600TPM-800
MaterialLDPE-PP-PPELDPE-PP-PPE
Capacity50~150 (Cycle/min)50~130 (Cycle/min)
Cutting width100~500 mm120~600 mm
Cutting length120~600 mm150~800 mm
Thickness of film0.04~0.15 mm0.04~0.15 mm
Film annulus diameterf500×1200 mmf500×1600 mm
Step motor1kw1kw
Transducer motor1.5kw2.2kw
Heater3kw3.5kw
Food-out motor0.25kw0.37kw
Ultrasonic1set1set
Conveying electrical0.55kw0.75kw
Food film motor0.55kw0.75kw
Sealing capacity10-30m/min10-30m/min
Cooling0.37kw0.37kw
Power15kw17kw
Overall dimension (L×W×H)mm8500×1800×18008650×1900×1800
Voltage50Hz 220v50Hz 220v
Press empty machine1900×1850×17002100×1850×1700
Packing dimension (L×W×H)mm1700×1500×19001900×1500×1900
