Yueqing Sandi Electric Co.,Ltd is one of the leading China 24v inverter manufacturers, welcome to wholesale cheap 24v inverter from our professional factory.

Technical Parameters

SDH-3000W

Function details:

Model

SDH-3000-121

SDH-3000-241

SDH-3000-481

SDH-3000-122

SDH-3000-242

SDH-3000-482

Rated Power

3000W

3000W

3000W

3000W

3000W

3000W

Max. Continuous Power

6000W

6000W

6000W

6000W

6000W

6000W

DC input voltage

12V

24V

48V

12V

24V

48V

AC output voltage

110VAC

220VAC

No-load current

1.3A

0.65A

0.32A

1.3A

0.65A

0.32A

AC output frequency

50Hz/60HZ

AC output waveform

Pure Sine Wave

Waveform distortion

THD<2%(Linear load)

Efficiency

>85%

>88%

>90%

>85%

>88%

>90%

DC input voltage range

10.5-15V

21-30V

42-60V

10.5-15V

21-30V

42-60V

Low Voltage Alarm

10.5+/-0.3V

21+/-0.3V

42+/-0.3V

10.5+/-0.3V

21+/-0.3V

42+/-0.3V

Low Voltage Shutdown

10+/-0.3V

20+/-0.3V

40+/-0.3V

10+/-0.3V

20+/-0.3V

40+/-0.3V

Over Voltage Protection

15.5+/-0.5V

31+/-1V

62+/-2V

15.5+/-0.5V

31+/-1V

62+/-2V

Low Voltage Recovery

12+/-0.5V

24+/-1V

48+/-2V

12+/-0.5V

24+/-1V

48+/-2V

Over Voltage Recovery

14.8V

29.5V

59V

14.8V

29.5V

59V


     Protective Function

Low/Over voltage: LED  Red light, automatic recovery



Over load: LED  Red light, automatic recovery



Over temperature : LED  Red light, automatic recovery



Short circuit: LED  Red light, automatic recovery



Input reverse connection: Fuse burn-out

Working Temp.

 0?-40?

Storage Temp. Humidity

-30?-70?

Dimension

480*240*140mm

Wight

10.5kg
